2027 Polaris RANGER XD 1500 NorthStar Premium Super Graphite
Get in Touch
Description
2027 Polaris RANGER XD 1500 NorthStar Premium Super Graphite
Part of our Extreme Duty class. The strongest, most capable and comfortable RANGER with all-season comfort and elevated in-cab features.
Standard Features
- 110 HP ProStar 1500cc engine & STEELDRIVE transmission
- 3,500-lb. towing & 1,500-lb. box capacity
- Factory-installed heating & air conditioning (HVAC)
- Electronic cargo box lift
- Pro Series 6,000-lb. winch with synthetic rope, Auto Stop, rapid rope recovery and wireless remote
- 30" Kenda Cross Trail tires and 15" wheels
- 3.07 rear drive gear ratio
- Lock & Ride MAX accessory integration
Trim Features
- Enclosed cab with power windows and fixed windshield
WEATHERPROOF YOUR PLANS
Enjoy advanced comfort and convenience with a fully enclosed cab system—complete with a heating and air conditioning system offering 5 different air flow settings.
POWER YOUR PRODUCTIVITY
RANGER XD 1500 NorthStar is powered by a 3-cylinder ProStar 1500cc engine. It pumps out 110 HP and 105 lb.-ft. of torque for effortless hauling and towing and confidence on tough terrain.
MAXIMUM DURABILITY & STRENGTH
The industry-exclusive STEELDRIVE transmission features a 100% steel-constructed belt. It’s designed to withstand heavier loads and require less maintenance than the rubber belt design commonly found in other UTVs. Plus, it’s fully sealed and liquid-cooled for maximum durability and longevity.
Info
Industry
Powersports
Make
Polaris
Model
RANGER XD 1500 NorthStar Premium
Trim
Super Graphite
Year
2027
MSRP
41499
Category
Side x Side
Subcategory
3-Passenger
Specs
Engine Cooling
Liquid
Engine Disp to Wgt
1498 cc
Drive Train
"Selectable on-demand all-wheel drive, AWD/2WD/Turf/Ultra Turf, Drive modes: Comfort, Standard, Sport, Tow/Haul"
Primary Drive
Drive mode-specific engine braking, hill assist, and creep in drive and reverse
Engine Type
4-stroke triple cylinder DOHC
Fuel System
Electronic fuel injection
Horsepower
110 hp
Transmission
STEELDRIVE automatic transmission: D/R/P
Cargo Bed
Bed Box: 43.4 x 56 x 13.4 in (110.2 x 142.2 x 34 cm)
Cargo Bed Capacity
Box Capacity: 1,500 lbs. (680 kg)
Weight (Dry)
2,790 lbs. (1265 kg)
Fuel Capacity
13.6 gal (51.5 L)
Fuel Type
Gas
Ground Clearance
15 in (38 cm)
Tow Capacity
3,500 lbs. (1588 kg)
Hitch
Standard 2 in (5 cm) receiver
Length
137 in (348 cm)
Width
65 in (165 cm)
Height
78 in (198 cm)
Max Payload
1,710 lbs. (775 kg)
Turning Radius
15.1 ft (4.6 m)
Wheelbase
95 in (241.3 cm)
Suspension (Front)
Dual arched A-arm 12 in (30.5 cm) travel
Suspension (Rear)
Dual arched A-arm, IRS 12 in (30.5 cm) travel
Front Tire
30 x 10-15; KENDA® CROSS TRAIL
Rear Tire
30 x 11-15; KENDA® CROSS TRAIL
Tire Ply Rating
8-ply
Wheels
15 in aluminum
Front Brake
Foot-activated and power-assisted, 4-wheel hydraulic disc with dual-bore front and rear calipers
Rear Brake
Foot-activated and power-assisted, 4-wheel hydraulic disc with dual-bore front and rear calipers
Parking Brake
Park in-transmission
Security
Polaris P.A.S.S. anti-theft system
Instrumentation
Driver forward information center with 4 in color display and analog speedometer and tachometers: user-selectable blue/red backlighting and brightness, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, oil pressure, transmission indicator, EPS indicator, voltmeter, service indicator and codes, seat belt reminder
Seats
3-person, superior contoured and bolstered bench seat with 3-point harness, adjustable driver seat, and flip-down arm rest
Steering
Tilt & telescoping adjustment | High-output EPS
Heater
Factory-installed heat, AC, defrost, recirculation with 5 different airflow settings
Speed Limiting
Speed limiting controlled in gauge
Lighting
LED headlights with LED taillights, LED dome light, door puddle lighting, interior accent lighting, lighting modes: low, high, accent, blackout. Blackout mode switches off the headlights and dims interior lighting
Electrical System
140-amp charging system, Polaris PULSE electrical system (3-position hood and 3-position roof), USB charger, trickle charger, 12-volt accessory outlet, battery trickle-charging port
Winch
Pro Series 6,000 LB Winch with synthetic rope, Auto Stop, and wireless remote
Vehicle Protection
Large steel bumper, full-coverage skid plate
Door Type
Powered window doors
Cargo System
Electronic lift dump box with Lock & Ride MAX accessory integration
Warranty
2-year limited warranty
